1. Material
The ladder will be manufactured from high-strength Aluminium Alloy (6063-T6 / 6061-T6 grade) .
The material should be corrosion resistant and lightweight.
2. Type
Two Section Extension Type Ladder
Extendable and retractable through Rope & Pulley mechanism.
3. Height
Closed Height: Approx. 3–4 meters
Extended Height: Approx. 6–8 meters (requirement के अनुसार)
4. Load Capacity
Minimum 150 kg safe working load।
5. Rungs (Steps)
Rungs shall be of anti-slip serrated design.
Rung spacing: 280–300 mm।
Rungs must be firmly fixed or hydraulically pressed into the ladder frame.
6. Side Rails
Heavy duty aluminium rectangular section side rails।
Thickness: Minimum 2.5–3 mm।
7. Safety Features
Non-slip rubber shoes / PVC foot caps।
Strong locking hooks / rung locks for safety।
Nylon / polypropylene rope for extension system।
Pulley heavy duty aluminium या stainless steel।
8. Surface Finish
Ladder natural aluminium finish या anodized / anti-corrosion finishIn
9. They are
Ladder IS 3696 (Part 2)Come
10. In Approx. 12–20 kg(size क
11. Application
Maintenance work
Electrical work
Industrial / warehouse use
Building maintenance
12. Warranty
Minimum 12 months manufacturer warranty
